Attachment 'wxToolBar_Embedded_DEMO.py'
Download 1 #!/usr/bin/env python2.3
2
3 """
4 wxToolBar_DEMO.py - Toolbar generation using embedded images.
5 WorkingWithToolBars @ http ://wiki.wxpython.org/WorkingWithToolBars
6 Chris.Barker@noaa.gov 200?
7
8 Updated and modified by Ray Pasco 2011-04-24
9 pascor@verion.net
10
11
12 # Note: I use python2.3 above because my system has 2.2, 2.1, and 1.5.2 installed also
13
14 This is demo of a number of things that can be done with toolbars.
15 When run from a console, it writes messages to indicate toolbar button events.
16
17 This includes :
18 - Having it managed by a Frame : the most basic way of creating a toolbar
19
20 - Placing a toolbar in a wxPanel with a sizer so that you can have a
21 custom panel with a toolbar attached, rather than a frame
22
23 - Placing multiple toolbars in a Panel. This could be done inside a frame, instead.
24
25 - Using a wxStaticBitmap on a toolbar : Use custom separator (one that's visible)
26 Do this if you don't like the one that comes with the stock widget,
27 or want the same look on all platforms.
28
29 - Making a set of buttons on a toolbar act like radio buttons : That is,
30 only one is shown to be pressed at a time.
31
32 A few things in the demo that are not strictly about toolbars :
33
34 - Multiple panels, each with its own toolbar.
35
36 - Uses code generated by the old version of img2py.py to embed icons into Python code.
37
38 """
39
40 import wx
41
42 # It's easiest to generate & manage embedded graphics data when it's in a single separate file.
43 import EmbeddedIconData as eid
44
45 #------------------------------------------------------------------------------
46
47 ID_ZOOM_IN_BUTTON = wx.NewId()
48 ID_ZOOM_OUT_BUTTON = wx.NewId()
49 ID_TEST_BUTTON = wx.NewId()
50 ID_MOVE_MODE_BUTTON = wx.NewId()
51
52 ID_ZOOM_IN_BUTTON2 = wx.NewId()
53 ID_ZOOM_OUT_BUTTON2 = wx.NewId()
54 ID_TEST_BUTTON2 = wx.NewId()
55 ID_MOVE_MODE_BUTTON2 = wx.NewId()
56
57 ID_TOOLBAR = wx.NewId()
58
59 #------------------------------------------------------------------------------
60
61 class TestPanel( wx.Panel ) :
62 """
63 A Panel class with one or two attached toolbars.
64 """
65
66 def __init__( self, parent, id=wx.ID_ANY, size=wx.DefaultSize, color="BLUE", numToolbars=1 ) :
67
68 wx.Panel.__init__( self, parent, id, wx.Point( 0, 0 ), size, wx.SUNKEN_BORDER )
69 self.WindowColor = color
70
71 ## Create the vertical sizer for the toolbar and Panel
72 box = wx.BoxSizer( wx.VERTICAL )
73 tb = self.BuildToolbar1()
74 box.Add( tb, 0, wx.ALL | wx.ALIGN_LEFT | wx.EXPAND, 4 ) # add the toolbar to the sizer
75
76 if numToolbars == 2 : # Do we want the second toolbar?
77 tb = self.BuildToolbar2()
78 box.Add( tb, 0, wx.ALL | wx.ALIGN_RIGHT , 4 )# This one gets aligned to the right
79
80 #Now add a Window to draw stuff to ( this could be any wx.Window derived control )
81 self.DrawWindow = wx.Window( self, -1, wx.DefaultPosition, wx.DefaultSize, wx.SUNKEN_BORDER )
82 box.Add( self.DrawWindow, 1, wx.EXPAND )
83
84 box.Fit( self )
85 self.SetAutoLayout( True )
86 self.SetSizer( box )
87
88 # this connects the OnPaint handler to when the DrawWindow needs to be re-painted
89 wx.EVT_PAINT( self.DrawWindow, self.OnPaint )
90
91 #end __init__
92
93 #-----
94
95 def BuildToolbar1( self ) :
96
97 """
98 creates one of the toolbars
99
100 The buttons act like radio buttons, setting a mode for the Panel
101 Only one of them is pressed at a time. The SetMode() method handles this
102
103 """
104
105 tb = wx.ToolBar( self, -1 )
106 self.ToolBar = tb
107 tb.SetToolBitmapSize( ( 21, 21 ) )# this required for non-standard size buttons on MSW
108
109 tb.AddTool( ID_ZOOM_IN_BUTTON, eid.GetPlusBitmap(), isToggle=True )
110 wx.EVT_TOOL( self, ID_ZOOM_IN_BUTTON, self.SetMode )
111
112 tb.AddTool( ID_ZOOM_OUT_BUTTON, eid.GetMinusBitmap(), isToggle=True )
113 wx.EVT_TOOL( self, ID_ZOOM_OUT_BUTTON, self.SetMode )
114
115 tb.AddTool( ID_MOVE_MODE_BUTTON, eid.GetHandBitmap(), isToggle=True )
116 wx.EVT_TOOL( self, ID_MOVE_MODE_BUTTON, self.SetMode )
117
118 tb.AddSeparator() # Invisible spacer
119
120 # A way to insert a custom separator.
121 tb.AddControl( wx.StaticBitmap( tb, wx.ID_ANY, eid.GetSeparatorBitmap() ) )
122
123 tb.AddSeparator() # Invisible spacer
124
125 tb.AddControl( wx.Button( tb, ID_TEST_BUTTON, "Button", wx.DefaultPosition, wx.DefaultSize ) )
126 wx.EVT_BUTTON( self, ID_TEST_BUTTON, self.ButtonAction )
127
128 tb.Realize()
129
130 return tb
131
132 #end BuildToolbar1 def
133
134 #-----
135
136 def BuildToolbar2( self ) :
137
138 """
139 Creates another toolbar. It looks the same, but acts a little different :
140 The buttons are independent, rather than acting like radio buttons
141
142 It also has a custom separator, created by adding a tall skinny bitmap.
143 """
144
145 tb = wx.ToolBar( self, id=wx.ID_ANY )
146 self.ToolBar2 = tb
147 tb.SetToolBitmapSize( (21, 21) ) # Square spacer equired for non-standard size buttons on MSW
148
149 tb.AddTool( ID_ZOOM_IN_BUTTON2, eid.GetPlusBitmap(), isToggle=True )
150 wx.EVT_TOOL( self, ID_ZOOM_IN_BUTTON2, self.ButtonPress2 )
151
152 tb.AddTool( ID_ZOOM_OUT_BUTTON2, eid.GetMinusBitmap(), isToggle=True )
153 wx.EVT_TOOL( self, ID_ZOOM_OUT_BUTTON2, self.ButtonPress2 )
154
155 tb.AddTool( ID_MOVE_MODE_BUTTON2, eid.GetHandBitmap(), isToggle=True )
156 wx.EVT_TOOL( self, ID_MOVE_MODE_BUTTON2, self.ButtonPress2 )
157
158 tb.AddSeparator() # Invisible spacer
159
160 # A way to insert a custom separator.
161 tb.AddControl( wx.StaticBitmap( tb, wx.ID_ANY, eid.GetSeparatorBitmap() ) )
162
163 tb.AddSeparator() # Invisible spacer
164
165 tb.AddControl( wx.Button( tb, ID_TEST_BUTTON2, "Button", wx.DefaultPosition, wx.DefaultSize ) )
166 wx.EVT_BUTTON( self, ID_TEST_BUTTON2, self.ButtonPress2 )
167
168 tb.Realize()
169
170 return tb
171
172 #end BuildToolbar2 def
173
174 #-----
175
176 def ButtonPress2( self, event ) :
177 print "%s Panel second toolbar button clicked" % self.WindowColor
178
179 def SetMode( self, event ) :
180
181 # Deselect all the buttons.
182 for id in [ID_ZOOM_IN_BUTTON, ID_ZOOM_OUT_BUTTON, ID_MOVE_MODE_BUTTON] :
183 self.ToolBar.ToggleTool( id, 0 )
184
185 # Select this button.
186 self.ToolBar.ToggleTool( event.GetId(), 1 )
187 if event.GetId() == ID_ZOOM_IN_BUTTON :
188 print "Mode set to Zoom In in the %s Canvas" % self.WindowColor
189
190 elif event.GetId() == ID_ZOOM_OUT_BUTTON :
191 print "Mode set to Zoom Out in the %s Canvas" % self.WindowColor
192
193 elif event.GetId() == ID_MOVE_MODE_BUTTON :
194 print "Mode set to Move in the %s Canvas" % self.WindowColor
195
196 def ButtonAction( self, event ) :
197 print "%s Canvas button clicked" % self.WindowColor
198 pass
199
200 def OnPaint( self, event ) :
201 dc = wx.PaintDC( self.DrawWindow )
202 dc.SetBackground( wx.Brush( wx.NamedColour( self.WindowColor ) ) )
203 dc.BeginDrawing()
204 dc.Clear()
205 dc.EndDrawing()
206
207 #end TestPanel class
208
209 #------------------------------------------------------------------------------
210
211 class TestFrame( wx.Frame ) :
212
213 def __init__( self, parent=None, id=wx.ID_ANY, title='Default Title',
214 pos=wx.DefaultPosition, size=( 600, 500 ) ) :
215
216 wx.Frame.__init__( self, parent, id, title, pos, size )
217
218 wx.EVT_CLOSE( self, self.OnCloseWindow )
219
220 #-----
221
222 Canvas1 = TestPanel( self, color = "RED" )
223 Canvas2 = TestPanel( self, color = "BLUE", numToolbars = 2 )
224
225 #Build the Toolbar
226 tb = self.CreateToolBar( wx.TB_HORIZONTAL|wx.NO_BORDER )
227 self.ToolBar = tb
228 tb.SetToolBitmapSize( ( 21, 21 ) )# this required for non-standard size buttons on MSW
229
230 tb.AddTool( ID_ZOOM_IN_BUTTON, eid.GetPlusBitmap(), isToggle=True )
231 wx.EVT_TOOL( self, ID_ZOOM_IN_BUTTON, self.SetMode )
232
233 tb.AddTool( ID_ZOOM_OUT_BUTTON, eid.GetMinusBitmap(), isToggle=True )
234 wx.EVT_TOOL( self, ID_ZOOM_OUT_BUTTON, self.SetMode )
235
236 tb.AddTool( ID_MOVE_MODE_BUTTON, eid.GetHandBitmap(), isToggle=True )
237 wx.EVT_TOOL( self, ID_MOVE_MODE_BUTTON, self.SetMode )
238
239 tb.AddSeparator() # Invisible spacer
240
241 tb.AddControl( wx.Button( tb, ID_TEST_BUTTON, "Button", wx.DefaultPosition, wx.DefaultSize ) )
242 wx.EVT_BUTTON( self, ID_TEST_BUTTON, self.ButtonAction )
243
244 tb.AddSeparator() # Invisible spacer
245
246 # A way to insert a custom separator.
247 tb.AddControl( wx.StaticBitmap( tb, wx.ID_ANY, eid.GetSeparatorBitmap() ) )
248
249 tb.AddSeparator() # Invisible spacer
250
251 msg = 'A Frame-Managed Toolbar - Try Resizing the Frame Horizontally !'
252 tb.AddControl( wx.StaticText( tb, -1, msg ) )
253
254 tb.Realize()
255
256 ## Create the horizontal sizer for the two panels
257 box = wx.BoxSizer( wx.HORIZONTAL )
258
259 box.Add( Canvas1 , 1, wx.EXPAND )
260 box.Add( Canvas2 , 2, wx.EXPAND )
261
262 box.Fit( self )
263 #self.SetAutoLayout()
264 self.SetSizer( box )
265
266 self.Show()
267
268 #end __init__
269
270 def SetMode( self, event ) :
271
272 # Deselect all the buttons.
273 for id in [ID_ZOOM_IN_BUTTON, ID_ZOOM_OUT_BUTTON, ID_MOVE_MODE_BUTTON] :
274 self.ToolBar.ToggleTool( id, 0 )
275
276 # Select this button.
277 self.ToolBar.ToggleTool( event.GetId(), 1 )
278 if event.GetId() == ID_ZOOM_IN_BUTTON :
279 print "Mode set to Zoom In in the Frame"
280
281 elif event.GetId() == ID_ZOOM_OUT_BUTTON :
282 print "Mode set to Zoom Out in the Frame"
283
284 elif event.GetId() == ID_MOVE_MODE_BUTTON :
285 print "Mode set to Move in the Frame"
286
287 def ButtonAction( self, event ) :
288 print "Button clicked in the Frame"
289 pass
290
291 def OnCloseWindow( self, event ) :
292 self.Destroy()
293
294 #end TestFrame class
295
296 #==============================================================================
297
298 if __name__ == "__main__" :
299
300 app = wx.App( redirect=False )
301
302 appFrame = TestFrame( None, wx.ID_ANY, "Embedded Graphics Toolbar Test",
303 pos=( 100, 100 ), size=( 550, 200 ) )
304 #app.SetTopWindow( appFrame )
305
306 app.MainLoop()
307
308 #end if
